Ufi Box Backups Of Devices /Box Readed Dump Here

Jeremmi

Active Member
Aug 3, 2018
73
86
Russia
Sonork ID
0
Meizu M6S
Emmc dump Google
P.S. After recording, with the programmer to erase cache and userdata.
Init bus...
VCC: 3.0 V, VCCQ: 2.8 V
Bus: 8 bit (HS SDR 52MHz)
Access mode: sector mode
Power supply: dual-voltage (1.70-1.95V, 2.7-3.6V)
Card/BGA: BGA (Discrete embedded) - High density MMC
Manufacturer ID: 0x15 (Samsung)
Product name: BJTD4R (0x424a54443452), rev: 0x03, serial number: 0xD110B412
Manufacturing date: май 2017
CID: 15010042 4A544434 5203D110 B4125428
CSD: D0270132 0F5903FF F6DBFFEF 8E40400C
EXT_CSD revision: 1.8 (MMC v5.1)
Partition info:
Boot1: 4096 KiB
Boot2: 4096 KiB
RPMB: 4096 KiB
User area: 29.12 GiB(31,268,536,320 bytes)
Cache size: 64 MiB
Partition configuration: 0x48
Boot acknowledge is sent during the boot operation
Boot partition 1 is enabled for boot
Partitioning support: 0x07
Device support partitioning feature
Device can have enhanced technological features
Device partitioning possible
Boot configuration protection: 0x00
Boot bus conditions: 0x01
Bus width: x4 (sdr/ddr), boot mode: sdr(default), reset bus width to x1 sdr(default)
Boot area write protection: 0x00
Power-on write protection: possible
Permanent write protection: possible
Lock status: not locked
EXT_CSD backup saved to "\\%BACKUPS%\BJTD4R_D110B412.ext_csd"
ANDROID System Info:
platform: exynos5, cpu abi: arm64-v8a
manufacturer: Meizu
board: MeizuM6s, name: MeizuM6s_RU
brand: Meizu, model: Meizu M6s
build id: NRD90M, version: 7.0 Nougat (Flyme 6.3.1.0RU)
build description: MeizuM6s_RU-user 7.0 NRD90M 1514974053 release-keys
crypto state: encrypted?


Dr.sunilsingh

Friend's Martview
Aug 2, 2018
402
823
india
Skype
[email protected]
Sonork ID
1681209
OPPO F7 8.1.0 Oreo ( CPH1811EX_11_A.26_181230 ) Backup UFI BOX Download By Dr.ResearchCenter Team

FILE DUMP OPPO F7 8.1.0 Oreo (
CPH1811EX_11_A.26_181230 ) 787 MIB



5056








By Dr.ResearchCenter Team


Dr.sunilsingh

Friend's Martview
Aug 2, 2018
402
823
india
Skype
[email protected]
Sonork ID
1681209
OPPO, F7 version: 8.1.0 Oreo (CPH1811EX_11_A.26_181230)

Init bus...
VCC: 3.3 V, VCCQ: 3.0 V
Bus: 1 bit (SDR 52MHz)
Access mode: sector mode
Power supply: dual-voltage (1.70-1.95V, 2.7-3.6V)
Card/BGA: BGA (Discrete embedded) - High density MMC
Manufacturer ID: 0x15 (Samsung)
Product name: 3V6CMB (0x335636434d42), rev: 0x02, serial number: 0xCBCDDAE8
Manufacturing date: Mar 2018
CID: 15010033 5636434D 4202CBCD DAE835BE
CSD: D0270132 0F5903FF F6DBFFEF 8E40400C
EXT_CSD revision: 1.8 (MMC v5.1)
Partition info:
Boot1: 4096 KiB
Boot2: 4096 KiB
RPMB: 16384 KiB
User area: 116.48 GiB(125,069,950,976 bytes)
Cache size: 64 MiB
Hardware reset function: 1
Partition configuration: 0x48
Boot acknowledge is sent during the boot operation
Boot partition 1 is enabled for boot
Partitioning support: 0x07
Device support partitioning feature
Device can have enhanced technological features
Device partitioning possible
Boot configuration protection: 0x00
Boot bus conditions: 0x02
Bus width: x8 (sdr/ddr), boot mode: sdr(default), reset bus width to x1 sdr(default)
Boot area write protection: 0x00
Power-on write protection: possible
Permanent write protection: possible
Lock status: not locked
ANDROID System Info:
platform: MT6771, cpu abi: arm64-v8a
manufacturer: OPPO
board: oppo6771_17331, name: CPH1811
brand: OPPO, model: CPH1811(A73)
build id: O11019, version: 8.1.0 Oreo (CPH1811EX_11_A.26_181230)
build description: full_oppo6771_17331-user 8.1.0 O11019 1546112879 release-keys
crypto state: encrypted?
Custom moviNAND command is not supported for this device(MMC51).

  • Love
Reactions: bronce

Jeeva8875

Member
Jun 26, 2019
11
0
Hai sir oppo a1k ufi box factory reset failed but phone is dead condition plz upload it oppo a1k dump file plz help


Jeremmi

Active Member
Aug 3, 2018
73
86
Russia
Sonork ID
0
SIR NEED REDMI NOTE 3 (KENZO) DUMP & emmc Repair File ExtCSD--Usererea--Boot1--Boot2--RPMB
Why would you?
Put clean emmc in the device and simply ask the firmware via ufi toolbox and the unit will operate.
if emmc is clean it defaults to start with userarea.
If you use used emmc, it is important that the rpmb block is clean...for example, a popular KMVTU000LM-B503 goes,
just do the upgrade before installing it.
And all will turn out, good luck.

Last edited:

Mukesh Saxena

Junior Member
Sep 26, 2017
2
0
india dehli
Why would you?
Put clean emmc in the device and simply ask the firmware via ufi toolbox and the unit will operate.
if emmc is clean it defaults to start with userarea.
If you use used emmc, it is important that the rpmb block is clean...for example, a popular KMVTU000LM-B503 goes,
just do the upgrade before installing it.
And all will turn out, good luck.
i am new user so mistakly erase give solution sir.
