Hello

I have managed to remove the Frp|Factory reset without Credits using DTpro.
I share my experience with you! First of all thanks to the support

We need to perform Testpoint
  • Tick Feature!
  • Load the Boot in the RSA|Server Section
  • We perform Authorize phone in the BROM tab
  • then we go to the PM tab > press Connect
    • ...We hope you read the information and partitions
  • we select Frp | UserData in partition list
  • Let's go again to BROM> authorize Phone
  • We Connect Through Testpoint Again
  • Now Let's PM> Press Wipe!!
    • We wait for the operation to end
      • Unlocked Devices.

  • Connecting in PM!
connect G20.png
30/03/2022 03:05:22 p. m. - Checking server 1:
30/03/2022 03:05:22 p. m. - Checking server 1: OK!
30/03/2022 03:05:22 p. m. - Connecting to server:
30/03/2022 03:05:22 p. m. - Connecting to server: OK!
30/03/2022 03:05:22 p. m. - Asking server for access:
30/03/2022 03:05:22 p. m. - Asking server for access: OK!
30/03/2022 03:05:22 p. m. - Sending data to server:
30/03/2022 03:05:22 p. m. - Sending data to server: OK!
30/03/2022 03:05:22 p. m. - Receiving data from server:
30/03/2022 03:05:22 p. m. - Receiving data from server: OK!
30/03/2022 03:05:22 p. m. - Info : Connect Device in Bootrom Mode
30/03/2022 03:05:22 p. m. - Brom Mode : Press Vol and Connect Usb Cable
30/03/2022 03:05:23 p. m. - Waiting for Phone..
30/03/2022 03:05:23 p. m. - BROM Port Found : MediaTek USB Port (COM24)
30/03/2022 03:05:23 p. m. - Driver Description : MediaTek Inc., usb2ser.sys,1-22-2016,3.2.0.0
30/03/2022 03:05:23 p. m. - Checking Comunication Channels..
30/03/2022 03:05:23 p. m. - Device INIT Handshake.. Okay
30/03/2022 03:05:24 p. m. - Chip : MT6765 [Helio P35/G35]
30/03/2022 03:05:24 p. m. - Fingerprint : [FD07660000] [00000000]
30/03/2022 03:05:25 p. m. - BL Version : FE [03]
30/03/2022 03:05:25 p. m. - Secure Boot Device : False
30/03/2022 03:05:25 p. m. - SL Authorization : False
30/03/2022 03:05:25 p. m. - DA Authorization : False
30/03/2022 03:05:25 p. m. - BL Version : FE [03]
30/03/2022 03:05:26 p. m. - Mediatek Download Agent Information..
30/03/2022 03:05:26 p. m. - Sign : MTK_DOWNLOAD_AGENT
30/03/2022 03:05:26 p. m. - ID : MTK_AllInOne_DA_v3.3001.09/05/2021.11:40_572407
30/03/2022 03:05:26 p. m. - Sending Boot [Auth]..
30/03/2022 03:05:26 p. m. - Sending Boot [PL]..
30/03/2022 03:05:31 p. m. - Sending Boot [EMI]..
30/03/2022 03:05:32 p. m. - Sending Boot [DA]..
30/03/2022 03:05:32 p. m. - BL Info : MTK_BLOADER_INFO_v35
30/03/2022 03:05:32 p. m. - BL File : preloader_t99653aa1.bin
30/03/2022 03:05:36 p. m. - Switching To High-Speed Vcom Mode...
30/03/2022 03:05:40 p. m. - Mode : [High-Speed] COM43 - MediaTek DA USB VCOM (Android) (COM43)
30/03/2022 03:05:40 p. m. - Drivers : MediaTek Inc.,usb2ser.sys [1-22-2016] [3.2.0.0]
30/03/2022 03:05:46 p. m. - Reading Partition Table..
30/03/2022 03:05:46 p. m. - Memory Type : eMMC
30/03/2022 03:05:46 p. m. - Partition Count : 53
30/03/2022 03:05:46 p. m. - Userdata : 115.18 GB
30/03/2022 03:05:47 p. m. - Rebooting Device..


  • Wipping parititons for to Unlocking!
Wipe G20.png

30/03/2022 03:09:26 p. m. - Checking server 1:
30/03/2022 03:09:26 p. m. - Checking server 1: OK!
30/03/2022 03:09:26 p. m. - Connecting to server:
30/03/2022 03:09:26 p. m. - Connecting to server: OK!
30/03/2022 03:09:26 p. m. - Asking server for access:
30/03/2022 03:09:26 p. m. - Asking server for access: OK!
30/03/2022 03:09:26 p. m. - Sending data to server:
30/03/2022 03:09:26 p. m. - Sending data to server: OK!
30/03/2022 03:09:26 p. m. - Receiving data from server:
30/03/2022 03:09:26 p. m. - Receiving data from server: OK!
30/03/2022 03:09:26 p. m. - Installing LibUsb Drivers..
30/03/2022 03:09:27 p. m. - Creating Device Service.. [LibUsb]
30/03/2022 03:09:27 p. m. - Info : Connect Device in Bootrom Mode
30/03/2022 03:09:27 p. m. - Brom Mode : Press Vol and Connect Usb Cable
30/03/2022 03:09:27 p. m. - Waiting for Phone..
30/03/2022 03:09:58 p. m. - BROM Port Found : MediaTek USB Port (COM24)
30/03/2022 03:09:58 p. m. - Driver Description : MediaTek Inc., usb2ser.sys,1-22-2016,3.2.0.0
30/03/2022 03:09:58 p. m. - Checking Comunication Channels..
30/03/2022 03:09:59 p. m. - Device INIT Handshake.. Okay
30/03/2022 03:10:00 p. m. - Hardware Code : 0766
30/03/2022 03:10:00 p. m. - HW Subcode : 8A00
30/03/2022 03:10:00 p. m. - HW Version : CA00
30/03/2022 03:10:00 p. m. - SW Version : 0000
30/03/2022 03:10:00 p. m. - HW Config : 000000E7
30/03/2022 03:10:00 p. m. - Secure Boot Device : True
30/03/2022 03:10:00 p. m. - SL Authorization : True
30/03/2022 03:10:00 p. m. - DA Authorization : True
30/03/2022 03:10:00 p. m. - Disabling Watchdog Timer..
30/03/2022 03:10:00 p. m. - Cpu : MT6765
30/03/2022 03:10:01 p. m. - Exploit : mt6765_payload.bin
30/03/2022 03:10:01 p. m. - Disabling Protection..
30/03/2022 03:10:01 p. m. - Opening Device Drivers Interface..
30/03/2022 03:10:01 p. m. - Device Response : 0xA1A2A3A4
30/03/2022 03:10:01 p. m. - Disconnecting from server:
30/03/2022 03:10:01 p. m. - Disconnecting from server: OK!
30/03/2022 03:10:01 p. m. - phone AUTH OK : END!
30/03/2022 03:10:15 p. m. - Info : Connect Device in Bootrom Mode
30/03/2022 03:10:15 p. m. - Brom Mode : Press Vol and Connect Usb Cable
30/03/2022 03:10:15 p. m. - Waiting for Phone..
30/03/2022 03:10:15 p. m. - BROM Port Found : MediaTek USB Port (COM24)
30/03/2022 03:10:15 p. m. - Driver Description : MediaTek Inc., usb2ser.sys,1-22-2016,3.2.0.0
30/03/2022 03:10:16 p. m. - Checking Comunication Channels..
30/03/2022 03:10:16 p. m. - Device INIT Handshake.. Okay
30/03/2022 03:10:17 p. m. - Chip : MT6765 [Helio P35/G35]
30/03/2022 03:10:17 p. m. - Fingerprint : [FD07660000] [00000000]
30/03/2022 03:10:18 p. m. - BL Version : FE [03]
30/03/2022 03:10:18 p. m. - Secure Boot Device : False
30/03/2022 03:10:18 p. m. - SL Authorization : False
30/03/2022 03:10:18 p. m. - DA Authorization : False
30/03/2022 03:10:18 p. m. - BL Version : FE [03]
30/03/2022 03:10:19 p. m. - Mediatek Download Agent Information..
30/03/2022 03:10:19 p. m. - Sign : MTK_DOWNLOAD_AGENT
30/03/2022 03:10:19 p. m. - ID : MTK_AllInOne_DA_v3.3001.09/05/2021.11:40_572407
30/03/2022 03:10:19 p. m. - Sending Boot [Auth]..
30/03/2022 03:10:19 p. m. - Sending Boot [PL]..
30/03/2022 03:10:24 p. m. - Sending Boot [EMI]..
30/03/2022 03:10:25 p. m. - Sending Boot [DA]..
30/03/2022 03:10:25 p. m. - BL Info : MTK_BLOADER_INFO_v35
30/03/2022 03:10:25 p. m. - BL File : preloader_t99653aa1.bin
30/03/2022 03:10:29 p. m. - Switching To High-Speed Vcom Mode...
30/03/2022 03:10:33 p. m. - Mode : [High-Speed] COM43 - MediaTek DA USB VCOM (Android) (COM43)
30/03/2022 03:10:33 p. m. - Drivers : MediaTek Inc.,usb2ser.sys [1-22-2016] [3.2.0.0]
30/03/2022 03:10:39 p. m. - Reading Partition Table..
30/03/2022 03:10:39 p. m. - Memory Type : eMMC
30/03/2022 03:10:39 p. m. - Partition Count : 53
30/03/2022 03:10:39 p. m. - Userdata : 115.18 GB
30/03/2022 03:10:39 p. m. - Wipping Partition : FRP
30/03/2022 03:10:42 p. m. - Wipping Partition : USERDATA
30/03/2022 03:10:45 p. m. - Rebooting Device..


  • Phone Unlocked
G20 Unlocked.jpg
