Medusa PRO v.1.3.9 is out!
Added support via eMMC (ISP) for Samsung SM-G316HU, Samsung SM-J320F, LG AS330, LG M400DY and support via USB for LG H961N, LG AS330 and LG M160!
Added «eMMC Write/Update firmware» for the numerous of Samsung eMMC chips.
Box firmware has been updated.
Uploaded new “Live logs” in to the Support Area.
Some fixes and improvements.
Medusa PRO v.1.3.9 Release Notes:
- Added support for the following models via eMMC:
- Samsung SM-G316HU - Read/Write/Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- Samsung SM-J320F - Read/Write/Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- LG AS330 - Read/Write/Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- LG M400DY - Read/Write/Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- Added support for the following models via USB:
- LG H961N - Read/Write/Full Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- LG AS330 - Read/Write/Full Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- LG M160 - Read/Write/Full Erase, Easy Repair, Partition Manager, Constructor for Repair Files
- Uploaded SRF for LG K430 into the Support Area («USER UPLOADED SRF» folder) (thanks to Mr. agrsat)
- Added «eMMC Write/Update firmware» for the following Samsung eMMC chips:
- KLM4G1FE3B-B001 (M4G1FB)
- KMS5U000KM-B308 (SSU00M)
- KMSJS000KM-B308 (SJS00M)
- KMVUS000LA-B304 (VUS00A)
- KLM8G2FE3B-B001 (M8G2FB)
- KMJJS000WA-B409 (JJS00A)
- KMKUS000VM-B410 (KUS00M)
- KMNJS000ZM-B205 (KJS00M)
- KMK7U000VM-B309 (K7U00M)
- KMN5X000ZM-B209 (N5XZMB)
- KLM8G1WEMB-B031 (8WMB3R)
- KMK7X000VM-B314 (K7XVMB)
- KMK5X000VM-B314 (K5XVMB)
We have tested and added Test Point (TP) pictures to force eMMC into Boot Mode for each of mentioned above eMMC chips.
To write/update eMMC firmware, please complete the following steps:
- Select «eMMC» interface option
- Select «Brand: eMMC_chips»
- Select eMMC chip part number in «Model:» software list
- Press «Help» button to view eMMC pinout and TP picture. Acknowledge the manual.
- Solder all necessary wires to connect eMMC (if necessary, solder TP wire to force eMMC into Boot Mode, Product name will be displayed as 000000)
- Press «Connect» button to connect eMMC (if necessary, connect TP to GND)
- When connection is successful, release (disconnect) TP wire from GND and go to «eMMC service» tab in the software
- Press «Write/Update firmware» button, select proper eMMC chip from the list and press "Write/Update eMMC firmware" button
NOTE: PLEASE DON’T SELECT INCORRECT eMMC (WITH NON-MATCHING PART NUMBER)! WRITING INCORRECT FIRMWARE WILL DAMAGE YOUR EMMC!
- Added auto-analyzing of TA (Trim Area) zone in Sony devices (structure, IMEI, lock status).
From now on software automatically checks TA zone and inform you, whether TA is correct or it is damaged.
You should remember, for successful repair of most Sony devices, their TA should be original and non-damaged.
- Box firmware has been updated to 1.19 version! In 1.19 firmware version we have improved eMMC detection procedure.
To update firmware automatically, it is necessary to connect the Box and only then run the software.
Also, you can update Box firmware manually via «Update Box Firmware» button at the «Welcome» tab in Medusa Pro software.
- Uploaded new “Live logs” in to the Support Area
- Some changes in log information
- All pinouts and repair procedures are described in the manual ("Help" button in the software)
Medusa - Ultimate Breakthrough in the Phone Repair!
Download Medusa PRO Software v.1.3.9
