iTunes Errors Problem & Solution

Hello
As We Know There Many Problem And Error In iPhone/Ipad/Mac During Update On Itunes.
Let We Try To Fix Much Known Error Code With Solution.





Error -1
Hardware - Error occurs when baseband cpu, baseband flash or baseband pm ic get damaged or dry
soldered from board or else some other hardware fault which preventing baseband function to updated during restore ios.


Error 1
Hardware - Related to error -1 but not directly point to bb cpu or flash might be something else hardware.


Error 2
Software - Check for issues with third-party security software.
Hardware - Connection issue between phone hardware via usb to computer. Could be firmware flash chip dry soldered.
Baseband circuits have problems: Power supply; Baseband power; Baseband CPU
Solution
Check power supply output of baseband power;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value


Error -2
Please reboot with iTunes
Solution
Reboot with Apple official software


Error 3
Hardware - BB or BB supporting components are damaged. Check BB voltage regulator chips.
Currently, there are two progress error messages: 1. If an error message appears after reboot to two-thirds of progress, mostly it is caused by baseband CPU physical damage
If an error message appears in the case of the reboot to 99% of progress, it means EEPROM fails to cache, it can be certain that EEPROM has faults
Solution
Check power supply output of baseband power;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value;
Repair with the instrument as there is a mismatch between baseband EEPROM and data


Error 4
Software - Check for issues with third-party security software.
Hardware - Connection issue between phone hardware via USB to the computer. Could be firmware flash chip dry soldered.


Error 6
Software - Unable to resize partition due to full storage problem at the final stage of updating the firmware.
The error may be bypassed (restart and do exit recovery) but you probably need to re-update it one more time
Hardware - Connection issue between phone hardware via USB to the computer. Could be nand chip Issue.


Error 9
The most common error which has too many reasons even vary on different iDevice models. All and 100% cause of error 9 not yet revealed as it not the same for all.
Software- Restart pc/mac. Re-install latest version of iTunes. Try with latest ios version clean install.
Try with a different pc. Try with original USB cable. Try with the different USB port on pc.
Hardware - Sufficient power/voltage not present to finish software operation. Battery, battery connector,
dock flex cable, charging ic and charging related parts, power ic, CPU, shorted caps on board, etc etc.


Error 10
Software - Try with a new IOS file. Direct restore from online.

Error 11
Software - Use the latest version of iTunes. New ios file. Restart pc.
Check the firmware package for completeness and the firmware name for errors
Solution
Re-download new firmware.


Error 12
Firmware shutdown verification
Solution
Re-download new firmware


Error 13
Software - Use the latest version of iTunes. Beta software issue. Try with a MAC computer with MAC OS.
Re-download new firmware, Check beta firmware package for completeness
Hardware - Use original USB cable. Don't use USB hub put direct.
USB connection for normality
Replace the reboot wire or dock flex of the phone.



Error 14
Software - Use the latest version of iTunes and MAC OS. Might be issues with third-party security software.
Hardware - Device isn't bootable. Nand issue. USB Problem. Check the USB connection and try other direct ports or maybe the USB cable is an older one.



Error-15
Mostly NAND has problems, without ruling out NAND power supply problems
Solution
Replace the NAND if it is damaged;
Reinstall the NAND if it has pseudo soldering;
Measure the mainboard GND resistance value if the path has problems, or maybe the power supply is not available


Error-16
In the path from baseband CPU to baseband EEPROM, mostly baseband EEPROM has problems
Solution
Check baseband EEPROM for pseudo soldering or damage, and measure mainboard GND resistance value if the path has problems


Error 17
Software - Try to restore with clean and new ios. Restore Direct from online.

Error 18
Software - Device file system is corrupted. Don't update but clean restore should solve this issue.

Error 20
Software - Problem with third-party security software. If it's happened with new iTunes try with older one. Usually happens when trying to downgrade. Try with beta ios.
Manually enter DFU mode to reboot again.
Hardware - Don’t use external hub direct connect to USB. Try with another and original USB cable. Try with different pc/mac.



Error 21
Mostly error 20 is a hardware issue which causes low power.
Software - Restore in dfu mode. Try with different pc, USB cable, USB port.
Hardware - There is not enough power to finish software operation. Check battery and its way, charging ic, sensor cables. Check nand. Remove the board from the housing,
only put the battery and charging/dock flex cable and try to restore software.


Error 23
Mostly hardware issue.
Software - Do usual troubleshot, iTunes, new ios etc.
Hardware - Might be a communication problem.
Check battery, bb CPU and bb flash.
Baseband circuits have the problem mostly caused by a short circuit
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged, and the part underwater damage is the peripheral capacitor or baseband power


Error-23
Error message -23 of iPad6 indicate the battery run out
Solution
Charge or change the battery


Error 26
Software - Try with new ios, direct restore from online through iTunes.
Hardware - Check regular flash ic.
The path from baseband CPU to EEPROM has problems
Solution
Check baseband CPU or EEPROM for pseudo soldering or damage, and measure mainboard GND resistance value if the path has problems


Error 27
Software - Just restore it don’t use update option. Use the latest iTunes and ios file.
Hardware - Check battery, battery connection, and USB connectivity.



Error 28
CPU or NAND has problems
Solution
Main CPU lower layer has pseudo soldering or damage;
In a few cases, NAND has problems, such as pseudo soldering or damage


Error 29
You might need to change the battery.
If iTunes is already open, quit and reopen it.
Make sure that you have the latest version of iTunes.
Check for issues with third-party security software.
Make sure that your USB cable, computer, and network are reliable. Then try twice more to restore your iPhone, iPad, or iPod.
If you still see the error message, you can check for outdated or modified software.


Error 31
Apple Mobile Device USB Drive Problem, reinstall latest iTunes, change USB cable, don’t use a hub. Try with another pc/mac.
Baseband circuits
Solution
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value to test the path


Error 34
Low disk space in your computer, related to the memory of your pc.

Error 37
Attempting to restore with an IPSW that was stitched with blobs, not for your device (Usually a good thing if restoring with a geek grade beta IPSW or
with your own creation). To boot, simply open redsn0w. Do fix recovery and tether boot after. Do not lock or device's LCD will fail.


Error 40
NAND chip is dead (confirm with ASR output from restore log).

Error 45
Same with Error 6, in terms of resizing partition issue. But this may occur at the very beginning of the restore process.

Error 47
Baseband circuits have problems: baseband EEPROM or baseband CPU
Solution
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value to test the path.



Error 48
Baseband CPU or baseband EEPROM is damaged, but baseband EEPROM is not necessarily damaged; repair with the instrument
Solution
Repair with the instrument as there is a mismatch between baseband EEPROM and data;
Check baseband EEPROM or baseband CPU for pseudo soldering or damage;
Corresponding parts should be replaced as baseband EEPROM and baseband CPU mismatch with main CPU data


Error 50
Baseband CPU has faults
Solution
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value to test the path


Error 53
Can be an error with iTunes. In this case, change your DNS to 8.8.8.8 and try again.
Hardware- a mismatch between security data and security hw. Check the home button.


Error 56
Most likely a dead/glitched Touch ID sensor. Try restoring the latest firmware in DFU mode.
Take out the SIM card and try restoring in DFU mode. If still occurring, take your device to apple.


Error 91
NAND circuits have problems
Solution
Replace the NAND if it is damaged;
Reinstall the NAND if it has pseudo soldering;
Measure the mainboard GND resistance value if the path has problems, or maybe the power supply is not available.



Error 1002
Baseband circuits or NAND circuits have problems
Solution
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value to test the path;
Replace the NAND if it is damaged; reinstall the NAND if it has pseudo soldering.
Error when restoring an old IOS, bad host file. Try to restore with latest ios with latest iTunes. Change USB cable and port. Try with another pc/mac.


Error 1003
Baseband circuits or NAND circuits have problems
Solution
Check power supply output of baseband power, focusing on checking whether the power supply is grounded, and if it is grounded, mostly the baseband CPU is damaged;
Check baseband power or baseband CPU for pseudo soldering or damage;
Check mainboard GND resistance value to test the path;
Replace the NAND if it is damaged; reinstall the NAND if it has pseudo soldering.



Error 1004
This is caused by a failure to match the Baseband Nonce currently in memory to the nonce returned in the Baseband Firmware SHSH blob.
Use TinyUmbrella and "Kick Device Out Of Recovery" to boot.


Error 1005
NAND circuits have problems
Solution
Replace the NAND if it is damaged;
Reinstall the NAND if it has pseudo soldering;
Measure the mainboard GND resistance value if the path has problems, or maybe the power supply is not available.



Error 1011
This is caused by recovery mode being in userland.

Error 1013
This means that the baseband did not get updated. Either remove the gs.apple.com entry from your host's file and let the baseband
upgrade or if you want to preserve the baseband just jailbreak at this point to boot it up.
Restart computer; change computer; reinstall system, if the device is always in restoring mode:
XP users can jump from restoring mode with ibus; MAC users can use iNdependence or similar other sw.


Error 1014
This occurs when you try to downgrade your device's baseband.

Error 1015
This error is common when downgrading iPhones and 3G iPads. The problem occurs when the device's baseband has a higher version
number than the baseband in the firmware you restored to.
Just set auto-boot true in iRecovery or use iREB/TinyUmbrella/RecBoot.1 In case this is not working use PwnageTool to create a custom firmware
WITHOUT the iPad baseband, put your device in pwned DFU Mode and restore via iTunes.


Error 1050
Bad response from gs.apple.com OR need iREB for preparing the device for restoring to custom IPSW

Error 1394
Older IOS. Try with latest one.
Baseband prevents the update itself. Sometimes happens with refurbish device.


Error 1413
Restart computer; change USB port, try with older iTunes, restore online. reinstall system. Try another pc/mac.

Error 1415
Restart computer; change USB port; reinstall the system.

Error 1417
Restart computer; change USB port; reinstall the system.

Error 1418
Restart computer; change USB port; reinstall the system.

Error 1428
Restart computer; change USB port; reinstall the system.

Error 1600
Custom firmware can't be restored on a device with DFU Mode. The software of the device isn't patched.
Using a jailbreak tool, enter a pwned DFU Mode. During that process, the software gets patched and the custom firmware should run without any problems.
If truly stuck (even with a regular iTunes Restore), edit the host's file.
GetDeviceID: failed for iBoot (experienced on Windows 8)
CPU circuits have problems
Solution-
Check the main CPU for pseudo soldering or damage;
Check CPU power supply or power supply path elements



Error 1601
CPU circuits have problems
Solution
Check the main CPU for pseudo soldering or damage;
Check CPU power supply or power supply path elements
Usb error, bad iTunes, registry/host issue in windows.


Error 1602
USB power supply or system has problems
Solution
Check for USB power supply or system problems
Restart computer; change computer; reinstall the system.
If this error occurred during an Apple TV restore, then unplug the Apple TV from the power cable, after you entered the recovery or DFU mode, and then try it again.


Error 1603
False kernel cache patch. Known on damaged bundles from unofficial PwnageTool distributions.

Error 1604
The device was not pwned (signature checks were not blocked). Custom firmware can't be restored. Can also happen when there's a problem with the IPSW.

Error 1611
NAND circuits have problems
Solution
Replace the NAND if it is damaged;
Reinstall the NAND if it has pseudo soldering;
Measure the mainboard GND resistance value if the path has problems, or maybe the power supply is not available.
iTunes tried to enter the Restore Mode, but the device turned back to the Recovery Mode.


Error 1618
Missing system files or corrupt data in iTunes installation. Try to uninstall iTunes,
restart the computer, install again. This error also occurs for iTunes in Windows 8 for reasons currently unknown.


Error 1619
iTunes is too old and couldn't read the iPhone in Recovery or DFU Mode. Please update iTunes and try it again.

Error 1644
IPSW was moved during prepare with iTunes. Try it again and don't move the IPSW.

Error 1646
iTunes expected the device to be in a different state (Example: booted into iOS rather than jumping to iBEC).

Error 1667
Occurs when the device is unplugged while the "iTunes will erase and restore your iPhone to
iOS and will verify the restore with Apple." dialog is shown. Check USB connections and try again.


Error 1669
Error message 1669 will appear in the case of EEPROM data error or loss, or burnout of iPhone6S dock connector
Solution
Repair with an instrument as there is a mismatch between baseband EEPROM and data;
Check baseband EEPROM for pseudo soldering or damage;
Corresponding parts should be replaced as baseband EEPROM and baseband CPU mismatch with main CPU data.


Error 2001
Check USB hub.

Error 2002
iTunes can't connect because another program is using it or it's disconnected during the Apple Server check.

Error 2003
Connection problem; change USB cable and check USB port.
sn0wbreeze failed to restore IPSW; unplug and plug iDevice and try again


Error 2005
A battery has problems; check battery connector
Solution
Check battery condition or detect the testing pin path
Problem connecting. Probably a hardware failure.
Supposedly reinstalling the USB drivers fixed the problem.


Error 2006
Replace the USB cable with a newer one and/or disconnect all other USB devices, then retry.

Error 2009
If you experience this issue on a Mac, disconnect third-party devices, hubs, spare cables, displays, reset the SMC, and then try to restore.
If you are using a Windows computer, remove all USB devices and spare cables other than your keyboard, mouse, and the device, restart the computer and try to restore.
If that does not resolve the issue, see Error 1604 above. If the issue persists, it may be related to conflicting security software on your computer.


Error 3002
Update to an older firmware isn't working, because Apple is no longer handing out SHSHs for the device/firmware combination.
Or a timeout checking Apple server - retry later.
This error also happens if you try to Update with a local TSS server (TinyUmbrella tool) and probably also when connecting to Cydia Server. Use Restore instead.
Error 3002 represents no update ramdisk when pressing Shift+Check for updates.


Error 3004
Battery, data wire, computer, and USB interface are unstable
Solution
Check USB circuits, data wire or computer.
No internet connection during the firmware restore.
iTunes can't connect to gs.apple.com. Maybe Port 80 and Port 443 is blocked. Open it on your router.


Error 3014
Bad hosts file. The SHSH request couldn't be completed. No connection to the Apple Server, Cydia Server or localhost (for TinyUmbrella).
iTunes can't connect to gs.apple.com. Maybe Port 80 and Port 443 is blocked. Open it on your router.



Error 3011
Bad hosts file. The SHSH request couldn't be completed. No connection to the Apple Server, Open your host file and remove any lines with gs.apple.com."

Error 3049
CPU circuits have problems
Solution
Check the main CPU for pseudo soldering or damage;
Check 1161111 CPU power supply or power supply path elements


Error 3123
Something dealing with movie rentals.

Error 3191
QuickTime may be corrupted. You must reinstall it before iTunes will work. Windows users, also try turning off Compatibility Mode for QuickTime

Error 3194
Occurs when trying to install an old firmware and Apple's server disallows the installation. The only solution is to have the SHSH blob backed up and modify the
host's file to point to Saurik's Cydia Server where they are backed up (or localhost if you have it yourself). Also happens if restoring to the latest iOS and the hosts point to Cydia. Remove gs.apple.com lines in the hosts file.
Another message that this error can display is "not eligible for requested build". Restore the latest IOS with the latest iTunes.


Error 3195
There is no SHSH blob for the firmware.
This is the same as "This device isn't eligible for the requested build." but with an cache error.


Error 3200
You are trying to update to a firmware, when in fact, there is only a Restore Ramdisk.

Error 4013
Connection to the device is lost after the "Preparing iPhone for Restore" step but before the phone is actually wiped causing it to boot normally.
Check USB connections and try again. Check battery and power way. Finally, check nand ic, re-hot it would be work.


Error 4015
CPU upper layer circuits have problems
Solution
Check main CPU upper layer for pseudo soldering or damage;
Check CPU power supply or power supply path elements



Error 9008
Error downloading, check the internet and try again.

Error 9807
Unknown error; try again

Error 11222
A security software you have installed may be conflicting with iTunes.

Error 11556
You're trying to access a section or a functionality that is not available in your country, for example, iCloud in some countries.

Error 13019
Seems to be an issue with syncing media to the device... It only seems to happen on jailbroken devices.
Create a new user, try syncing with new user's library. If that fails, restore. If it doesn't fail, then something on YOUR iTunes Library is causing the error.


Error 20000
This error can also be caused by the iDevice rebooting during the "Extracting Firmware" stage of restore.

Error 20008
This happened on a Mac with TinyUmbrella running before restoring a firmware to the Apple TV.

0x80090318
Something dealing with programs monitoring Winsock.

“0xEXXXXXX”
Mostly USB relates issue either its software or hardware. So just check all hw and sw which is related to USB.

0xE800000F
Reboot your iDevice and pc/mac with original USB cable try again.

0xE8000001
Device was suddenly unplugged. iTunes couldn't connect with the device. Try it again

0xE8000022
Error in your firmware files. Restore with the latest file direct from online/real time.

0xE800003D
False permissions in the Carrier Bundle folder. Restore, update or fix the permissions from the carrier bundle to update the carrier settings via iTunes.

0xE800006B
The device was suddenly unplugged. iTunes couldn't connect with the device. Try it again.

0xE8000065
Error on USB connection. Unplug the device, reboot it, and plug it in again.

0xE8008001
IPA signature verification failed.

0xE800001F
Usb or registry on windows pc issue.

0xE8800084
Check USB port and cable. Reinstall iTunes. Update pc/mac.

Note-I am Not iPhone Hardware Or Software Expert I Collect All Data From Internet (Google)And Some Forum All Credit Goes To Original Author I Just Want To Help This Forum User, Thank You Very Much.

Last edited:
Status
Not open for further replies.
Top
